IS181GB Smart Switch 1.8V Low Voltage 6A High Current Ultra-Low 28mΩ RDS(on) Fast 15ns Switching ESD Protection DFN2x2 Package for Portable/IoT Devices
FEATURES
• Low Profile Package
• AC Isolation Voltage 3750VRMS
• CTR Selections Available
• Wide Operating Temperature Range -55°C to +110°C
• Lead Free and RoHS Compliant
• UL File E91231 model “FPT1” and “FPT2”
APPLICATIONS
• Computer Terminals
• Industrial System Controllers
• Measuring Instruments
• Signal Transmission between Systems of Different Potentials and Impedance
DESCRIPTION
The IS181 series of optocoupler consists of an infrared light emitting diode optically coupled to an NPN silicon photo transistor in a space efficient Mini Flat Package.
INFORMATION
| Category | | |
| Manufacturer | Isocom Components 2004 LTD | |
| Series | - | |
| Packaging | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® | |
| Part Status | Active | |
| Number of Channels | 1 | |
| Voltage - Isolation | 3750Vrms | |
| Current Transfer Ratio (Min) | 100% @ 5mA | |
| Current Transfer Ratio (Max) | 600% @ 5mA | |
| Turn On / Turn Off Time (Typ) | - | |
| Rise / Fall Time (Typ) | 4µs, 3µs | |
| Input Type | DC | |
| Output Type | Transistor | |
| Voltage - Output (Max) | 80V | |
| Current - Output / Channel | 50mA | |
| Voltage - Forward (Vf) (Typ) | 1.2V | |
| Current - DC Forward (If) (Max) | 50 mA | |
| Vce Saturation (Max) | 200mV | |
| Operating Temperature | -55°C ~ 100°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 4-SMD, Gull Wing | |
| Supplier Device Package | - | |
| Base Product Number |
