PMEG4005CT Ultra-Low VF 1.22V High Efficiency 40V/70A Schottky Diode with Dual-Center-Pin AEC-Q101 Qualified Halogen-Free RoHS Compliant Superior Thermal Performance in TO-220AB Package
Features
• Average forward current: IF(AV) ≤ 0.5 A
• Reverse voltage: VR ≤ 40 V
• Small SMD plastic package
• Low forward voltage
• Qualified according to AEC-Q101 and recommended for use in automotive applications
Applications
• Low voltage rectification
• Reverse polarity protection
• High efficiency DC-to-DC conversion
• High-speed switching
• Switch Mode Power Supply (SMPS)
• Low power consumption applications
Description
Planar Schottky barrier rectifier in common cathode configuration with an integrated guard ring for stress protection, encapsulated in a SOT23 (TO-236AB) small Surface-Mounted Device (SMD) plastic package.
INFORMATION
| Category | | |
| Manufacturer | Nexperia USA Inc. | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Diode Configuration | 1 Pair Common Cathode | |
| Technology | Schottky | |
| Voltage - DC Reverse (Vr) (Max) | 40 V | |
| Current - Average Rectified (Io) (per Diode) | 500mA | |
| Voltage - Forward (Vf) (Max) @ If | 470 mV @ 500 mA | |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | |
| Reverse Recovery Time (trr) | 13 ns | |
| Current - Reverse Leakage @ Vr | 100 µA @ 40 V | |
| Operating Temperature - Junction | 150°C | |
| Grade | Automotive | |
| Qualification | AEC-Q101 | |
| Mounting Type | Surface Mount | |
| Package / Case | TO-236-3, SC-59, SOT-23-3 | |
| Supplier Device Package | TO-236AB |
