1SS404 andamp; H3F Ultra-High Speed Switching (Trrandlt;60ns) Low VF Compact Design High Reliability Low Power Loss ESD Protection RoHS Compliance Cost-Effective for Automotive andamp; Industrial Apps
andnbsp;
Features
Ultra-High Switching Speed: Features an extremely short reverse recovery time, which is its most important characteristic.
Small Package: Comes in the SOD-523 package, which is very small (approximately 1.2mm x 0.8mm), saving printed circuit board (PCB) space.
Low Power Consumption: Exhibits low forward voltage and low reverse current.
High Reliability: Features a glass package that offers good stability and durability.
andnbsp;
Applications
Detection and rectification in high-frequency circuits
High-speed switching circuits
RF circuits in the VHF/UHF bands
Portable electronic devices (due to its small size and low power consumption)
Polarity protection circuits
Signal clamping circuits
andnbsp;
Description
The 1SS404,H3F is a silicon epitaxial planar switching diode housed in a very small SOD-523 (also known as SC-79) package. Its core design goal is to achieve extremely high switching speed and very low reverse recovery time, making it ideally suited for high-frequency circuit applications.
andnbsp;
INFORMATION
| Category | andnbsp; | |
| Mfr | andnbsp; | |
| Series | - | andnbsp; |
| Packaging | Tape andamp; Reel (TR) Cut Tape (CT) Digi-Reelandreg; | andnbsp; andnbsp; andnbsp; |
| Part Status | Active | andnbsp; |
| Technology | andnbsp; | |
| Voltage - DC Reverse (Vr) (Max) | 20 V | andnbsp; |
| Current - Average Rectified (Io) | 300mA | andnbsp; |
| Voltage - Forward (Vf) (Max) @ If | 450 mV @ 300 mA | andnbsp; |
| Speed | Fast Recovery =andlt; 500ns, andgt; 200mA (Io) | andnbsp; |
| Current - Reverse Leakage @ Vr | 50 andmicro;A @ 20 V | andnbsp; |
| Capacitance @ Vr, F | 46pF @ 0V, 1MHz | andnbsp; |
| Mounting Type | andnbsp; | |
| Package / Case | andnbsp; | |
| Supplier Device Package | USC | andnbsp; |
| Operating Temperature - Junction | 125anddeg;C (Max) | andnbsp; |
| Base Product Number |
