BAS70W-7-F 70V 200mA Dual Series Schottky Diode with 1V Low Vf 4ns Fast Switching SOD-123 Package High Efficiency AEC-Q101 Qualified Tape & Reel Packaging
Features
Low Turn-on Voltage
Fast Switching
PN Junction Guard Ring for Transient and ESD Protection
Ultra-Small Surface Mount Package
Totally Lead-Free & Fully RoHS Compliant
Halogen and Antimony Free. “Green” Device
Applications
1:High-frequency rectification
2:Signal demodulation circuits
3:Reverse polarity protection
4:DC-DC converter circuits
5:Automotive electronic systems
6:Portable and consumer electronics
Description
The BAS70W-7-F is a high-performance dual series Schottky barrier diode designed for high-speed switching applications. Encapsulated in a compact SOD-123 surface-mount package, it combines low forward voltage with fast switching characteristics, making it ideal for space-constrained and efficiency-critical designs.
INFORMATION
| Category | | |
| Mfr | | |
| Series | - | |
| Packaging | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® | |
| Part Status | Active | |
| Technology | | |
| Voltage - DC Reverse (Vr) (Max) | 70 V | |
| Current - Average Rectified (Io) | 70mA | |
| Voltage - Forward (Vf) (Max) @ If | 1 V @ 15 mA | |
| Speed | Small Signal =< 200mA (Io), Any Speed | |
| Reverse Recovery Time (trr) | 5 ns | |
| Current - Reverse Leakage @ Vr | 100 nA @ 50 V | |
| Capacitance @ Vr, F | 2pF @ 0V, 1MHz | |
| Mounting Type | | |
| Package / Case | | |
| Supplier Device Package | SOT-323 | |
| Operating Temperature - Junction | -55°C ~ 125°C | |
| Base Product Number |
