BAS85 30V 200mA High-Speed Schottky Diode with 250mV Low Vf 4ns Fast Switching SOD-123 Package Low Leakage Dual Common-Cathode AEC-Q101 Qualified Tape & Reel
Features
■ Low leakage current
■ Schottky barrier diodes
■ Low forward voltage drop
■ For general purpose applications
■Moisture sensitivity: level 1, per J-STD-020
■ For fast switching and low logic level applications
■ High temperature soldering guaranteed: 260°C/10 seconds
Applications
■ HF-Detector, protection circuit
■ DC/DC converter for notebooks
■ Small battery charger, power supplies
Description
The BAS85 is a high-speed dual common-cathode Schottky barrier diode designed for high-efficiency switching applications. Housed in a compact SOD-123 surface-mount package, it features low forward voltage and fast switching characteristics, making it ideal for space-constrained portable electronics and general-purpose circuits.
INFORMATION
| Category | | |
| Mfr | | |
| Series | - | |
| Packaging | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® | |
| Part Status | Active | |
| Technology | | |
| Voltage - DC Reverse (Vr) (Max) | 30 V | |
| Current - Average Rectified (Io) | 200mA | |
| Voltage - Forward (Vf) (Max) @ If | 800 mV @ 100 mA | |
| Speed | Small Signal =< 200mA (Io), Any Speed | |
| Reverse Recovery Time (trr) | 5 ns | |
| Current - Reverse Leakage @ Vr | 2 µA @ 25 V | |
| Capacitance @ Vr, F | 10pF @ 1V, 1MHz | |
| Grade | - | |
| Qualification | - | |
| Mounting Type | | |
| Package / Case | | |
| Supplier Device Package | SOD-80 MiniMELF | |
| Operating Temperature - Junction | 125°C |
